Features Dual ES9039Q2M DACs For Superior Clarity & Hi-Res Audio

Topping DX5 II is equipped with two independent ESS ES9039Q2M DAC chips, one per channel, delivering higher signal-to-noise ratio (SNR), greater dynamic range (DNR) and lower distortion than its predecessor. This configuration ensures a truly high-resolution and detailed audio performance.

Embeds Next-Gen X-Hybrid Amplification Architecture For Enhanced Performance

Topping DX5 II introduces the X-Hybrid system, a breakthrough evolution of the NFCA architecture. It employs a triple-stage hybrid amplifier design featuring a discrete input stage, a discrete output stage, and an op-amp-based gain stage. This layout retains NFCA’s ultra-low distortion and high dynamic range, while improving efficiency and reducing both static power consumption and heat output. Despite its compact form, it houses a fully balanced, quad-channel amplifier.

Utilises Custom I/V Conversion To Unlock Full DAC Potential & 12V Trigger

Topping DX5 II integrates a self-developed I/V (current-to-voltage) conversion circuit to maximise the performance of the DAC. This compact and efficient design delivers reduced noise and lower distortion, achieving outstanding audio fidelity without sacrificing internal space. It supports 12V Trigger input and output, allowing it to be activated by other devices or to trigger external components. This ensures seamless power synchronisation across your audio setup.

Versatile Headphone Output For Any Setup & LDAC Wireless With Bluetooth 5.1

Topping DX5 II provides 6.35mm single-ended, 4.4mm balanced, and 4-pin XLR headphone outputs, catering to everything from low-impedance headphones to highly sensitive IEMs. With a noise floor of just 1.8uVrms, it delivers an exceptionally clean background. Boasting an output power of 7600mW x 2, it drives most headphones with ease. It features a Qualcomm QCC5125 chip with Bluetooth 5.1 support. It handles up to 96kHz/24-bit audio wirelessly and is fully compatible with LDAC, aptX Adaptive, aptX HD, aptX, AAC, and SBC, delivering CD-quality and beyond.

Fused With Aurora UI & 2-Inch Display Featuring Control Buttons & Knob

Topping DX5 II includes a 2.0-inch full-colour Aurora UI display with three buttons and a multifunction knob, offering quick access to settings and output modes. Users can choose from 9 background colours and toggle between VU meter, FFT and playback info. The knob is customisable for personal preferences, and the system supports bilingual switching between English and Chinese right from the first boot.

Tailor Your Listening Experience With 10-Band Precision PEQ System

Topping DX5 II features a newly developed 10-band high-precision PEQ system. Users can adjust frequency, gain, and Q-factor for each band, import target and raw curves, and save multiple profiles. This desktop software-based PEQ supports up to 192kHz/32-bit PCM and enables independent tuning for headphones and speakers to match your ideal sound signature.

Plug-and-Play Across Various Platforms With Exceptional Audio Performance

Topping DX5 II offers broad compatibility with Windows 10/11, macOS, Linux, iOS, and Android. Powered by the XMOS XU316 USB controller and Thesycon driver (for Windows ASIO), it supports PCM up to 768kHz/32-bit and native DSD512. This ensures stable performance and exceptional sound detail across platforms.

Features Headphone Crossfeed For More Natural & Accurate Sound

Topping DX5 II features an advanced convolution-based headphone crossfeed that accurately simulates HRTF and room acoustics, improving spatial depth and imaging while reducing the in-head localisation and close-ear effect common to headphone listening. Precisely calibrated to preserve tonal accuracy, it avoids the distortion often introduced by simple frequency flattening, and includes an enhanced BS2B-based simplified mode for a more relaxed, speaker-like presentation, ideal for listeners who want natural spatial realism without losing the intimacy of headphones.
